06-07 Duramax LBZ Pusher Intakes Compound Turbo Kit

  • Sale
  • Regular price $3,150.00


Features
  • Compatible with most Borg Warner S400 frame chargers and Garrett chargers
  • CNC machined and laser cut flanges for flawless mounting to your Duramax engine
  • Fully TIG welded with precise settings to produce beautiful welds and optimal penetration without impacting air flow.
  • The overall design and location of all components allows easy access and installation
  • Base kit includes 3" Pusher Max HD Charge Tube that properly supports the factory y-bridge at over 70 PSI of boost
  • Can be optioned with Pusher SuperMax Y-Bridge
  • 3.5" intermediate charge pipe and Garrett turbo inlet
  • O-ring seal at Garrett turbo inlet flange
  • 5" Cold Air Intake with large inverted cone filter
  • The Intermediate Exhaust Pipe is routed so no modifications need to be made to existing "low pressure" A/C lines and is hydro-formed to smoothly transition and match the S400 turbine inlet
  • Aluminum coolant overflow tank included and color matched
  • 4" down pipe with Patent Pending smooth flow flange. Installs without relocating the factory fuel filter housing or A/C dryer
  • All fittings and oil/water lines are premium quality from well known manufactures
  • Heavy duty 4-ply silicone couplers and full stainless t-bolt clamps at every boosted connection
  • Extreme duty turbo mount
  • Includes CCV reroute kit
  • S400 charger is placed in the optimal location for minimal impact to passenger side plastic inner fender and for optimal routing of every component in the system
  • Included is every nut, bolt, hose, clamp, and even wire loom for a beautiful install
  • Various powder coat colors available - all colors that don't show a lead time are usually in stock and ship same or next day
